簡單的說，電機轉矩是指其轉動力量的大小，是電機拖動負載能力的具體表現。在電機產品的性能參數中，以額定轉矩、轉矩和轉矩表征其不同狀態下的性能指標。
轉矩是電機起動性能的特性，額定轉矩是電機額定運行條件下對應的力能指標，而轉矩則反映電機的過載能力；不同的產品特性和使用工況對轉矩的要求不同。
對照同中心高、同功率但不同極數的電機可以發現，多極低轉速電機的轉矩較大，在電機的短路試驗中可以發現，較小規格的少極電機，制動相對容易，而多極的低轉速電機制動就比較困難。從電機的外觀特征比較，除特別小或特別大的規格電機外，同樣中心高同功率的電機，低速電機的軸伸直徑比較大，因?yàn)槠溥\(yùn)行中承載的負載要比較大，這也是針對于電機轉矩特性的尺寸保證要求。
從電機轉矩的計算公式（T=9550 P / n ）可以看出，當電機功率相同時，低速電機對應的轉矩較大。
電機軸伸是傳動的關鍵零部件，除電機與設備的對接尺寸控制外，電機軸伸的直徑大小、軸的材質，以及具體的加工控制要求，都直接影響著電機的轉矩能力體現，是一種機械能力表現。
當電機的轉矩超過其可以承當?shù)姆秶鷷r，即電機發生過載，電機的電流會因?yàn)檫^載出現大幅增加，導致繞組發生過熱燒毀問題；即使電機繞組能滿足過載要求，就電機的軸而言，過載意味阻力矩大，作用在軸上力矩太大時，會對軸伸造成直接的傷害，特別是對于軸伸加工不太規范的情況，容易發生電機軸伸撓曲或斷裂的質量事故。
Simply put, motor torque refers to the magnitude of its rotational force, which is a specific manifestation of the motor's ability to drag loads. In the performance parameters of motor products, the performance indicators under different states are characterized by rated torque, minimum torque, and maximum torque.
The minimum torque is a characteristic of motor starting performance, the rated torque is the corresponding force energy index under the rated operating conditions of the motor, and the maximum torque reflects the overload capacity of the motor; Different product characteristics and usage conditions have different requirements for torque.
By comparing motors with the same center and high power but different pole numbers, it can be found that multi pole low speed motors have higher torque. In the short circuit test of the motor, it can be found that small pole motors with smaller specifications are relatively easy to brake, while multi pole low speed motors are more difficult to brake. From the comparison of the appearance characteristics of the motor, except for motors with particularly small or large specifications, motors with the same center height and power have a larger shaft extension diameter for low-speed motors because they carry a larger load during operation, which is also a size guarantee requirement for motor torque characteristics.
From the calculation formula of motor torque (T=9550 P/n), it can be seen that when the motor power is the same, the torque corresponding to the low-speed motor is larger.
Motor shaft extension is a key component of transmission. In addition to controlling the docking size between the motor and equipment, the diameter of the motor shaft extension, the material of the shaft, and specific processing control requirements all directly affect the torque capability of the motor, which is a manifestation of mechanical capability.
When the torque of the motor exceeds its acceptable range, that is, the motor is overloaded, and the current of the motor will increase significantly due to the overload, causing the winding to overheat and burn out; Even if the motor winding can meet the overload requirements, for the motor shaft, overload means a large resistance torque. When the torque acting on the shaft is too large, it can cause direct damage to the shaft extension, especially for non-standard shaft extension processing, which can easily lead to quality accidents such as motor shaft bending or fracture.
